Frameset
Frame
670106
High-Tensile Steel, TIG-Welded
Front Frame
Tadpole Crank Boom, Chromoly Steel
Left Fork
Custom-Cast High-Tensile Steel, Threadless Stem, Disc Mount
Right Fork
Custom-Cast High-Tensile Steel, Threadless Stem, Disc Mount
Drivetrain
Rear Shifter
SunRace 7-Speed Twist Shifter
Rear Derailleur
SunRace, Long Cage
Freewheel
(7-Speed) 13-32T
Crank Set
3-Piece Alloy W/Integrated Chain Ring, 38T, 170mm, Black
Bottom Bracket
Sealed Cartridge, 68 x 113.5mm
Chain
K.M.C. 1/2 x 3/32'' (286 Links)
Chain Tube Bracket
Double Spring w/Hardware
Chain Tube Clamp
Clamp w/Hardware
Pedals
Resin Body w/Alloy Cage, 9/16" Axle
Brakes
Front Brake
Dual Promax Mechanical Disk, 160mm Rotor
Components
Headset
Steel, Caged Bearings, 28.6 x 34 x 30mm, Black
Right Handlebar
Tadpole Right Handlebar w/28.6mm Steerer Clamp
Left Handlebar
Tadpole Left Handlebar w/28.6mm Steerer Clamp
Grips
Kraton Rubber, 130mm Left / 65mm Right, Black/Gray
Front Brake Lever
Left Brake, Linear Pull, w/Lock, Black/Silver
Rear Brake Lever
Right Brake, Linear Pull, w/Lock, Black/Silver
Wheels
Front Hub
Alloy, 36H x 14G Tadpole, Disc, Black
Rear Hub
Alloy, 36H x 14G with Q/R Axle, Black (For Freewheel)
Front Rim
20'' x 36H x 14G, Alloy, Black
Rear Rim
20'' x 36H x 14G, Alloy, Black
Spokes
14G Stainless Steel with Brass Nipples, Black
Front Tire
Kenda Kwest 20 x 1.50", Black Wall
Rear Tire
Kenda Kwest 20 x 1.50", Black Wall
Replacement Parts
Head/Derailleur Tube Cap
Head/Derailleur Tube Cap
Steering Linkage
Tadpole 522mm Black
Left Rod End
Left Hand Thread
Right Rod End
Right Hand Thread
Front Axle
Tadpole Axle Set
Seat Frame
50181
R-Type 1-Pc Steel, Black
Seat Mesh
R-Type 1-Pc Seat Back Mesh
Seat Mount
Steel for Eco Delta/Tad 50mm TT
Seat Mount Binder
QR M6x95mm Alloy, XL Lever
Upper Strut
Steel 150mm Black
Upper Strut Washer
Curved Nylon Washer
Lower Strut
Steel, Pin Type, 700mm Universal
Lower Strut Slide Bolt
Lower Strut Bolt and Nut
Strut Peg QR
Steel Pin, QR
