Frameset
Frame
670831
High Tensile Steel, TIG-Welded
Fork
28772
1-1/8'' High Tensile Steel, Curved Tapered Legs, Double Eyelets
Drivetrain
Crank Set
211397
3-Piece Alloy W/Integrated Chainring, 165mm
Chainwheel
Steel, 36T x 1/2'' x 1/8''
Bottom Bracket
211398
Sealed Cartridge
Freewheel
18350
20T x 1/2" x 1/8"
Chain
16555
1/2" x 1/8", 130 Links
Pedals
41514
Plastic, 9/16", Black Platform
Pedals
41560
Plastic, 9/16", Black Platform
Brakes
Front Brake
120074
Alloy, Linear Pull
Rear Brake
120222
Promax DSK-300 Mechanical Disk, 160mm Rotor
Brake Lever
12415
Alloy, Linear Pull W/Parking Lock, Black/Silver
Components
Handlebar
33769
Steel, 27.6" Wide x 9" Rise x 25.4mm Clamp
Stem
570079
Steel, 25.4mm, 205mm Quill x 60mm Ext
Headset
35314
Steel, Caged Bearings, 25.4 x 34 x 30mm
Grips
31301
Foam, Black
Saddle
6702132
Western Style, Black
Seat Post
6702175
Steel, 12"
Seat Clamp / Binder Bolt
51190
Integrated Bolt/Nut Type, Silver
Wheels
Front Wheel
640658
24" x 1.75" x 36H x 12G Alloy-Trike with 350W Hub Motor
Rear Wheel
6702281
24" x 1.75 x 36H x 14G Alloy-Trike, Bolt-On
Front Hub
350W x 36V Silent DC Motor, 36H x 12G
Rear Hub
6702194
Steel, Large Flange, with Cartridge Bearings
Spokes
12G Front, 14G Rear, Stainless Steel
Rims
470698
24" x 36H x 12G, Alloy
Tires
59287
24" x 1.75, Black Wall
Tubes
6306
24" x 1.75", Schrader Valve
Accessories
Front Fender
6702155
Steel, Full Wrap, Single Strut, Stainless Steel
Basket
6702180
Steel, Vinyl Coated, 21" Long x 15" Wide x 9" High
Replacement Parts
Frame Rear Unit
670832
High Tensile Steel, TIG-Welded, Disc and Der Compatible
Seat Support Bar
6702135
Steel, 19"
Chainguard
290376
Steel, Painted
Rear Unit Hardware
6702210
Rear Unit Hardware (Includes (4) bolts, (6) nuts, (4) washers)
Rear Unit Bearing
6702184
Rear Unit Bearing for 15mm Axle (Quantitiy of (4) needed for rear unit)
Rear Unit Axle Complete
6702191
Rear Unit Axle, 15mm x 765mm (Includes (1) axle, (2) nuts, (2) washers, (1) axle spacer)
Rear Unit Axle Nut
6702204
Rear Unit Axle Nut (For 15mm / 17mm axle)
Rear Unit Axle Washer
6702192
Rear Unit Axle Washer (For 15mm axle)
Rear Unit Axle Spacer
6702193
Rear Unit Axle Spacer, 20mm (For 15mm axle)
Rear Unit Axle Key
6702203
Rear Unit Axle Key (For 15mm/17mm axle)
Freewheel Adaptor
6702199
Freewheel Adapter (For 15mm axle, includes (2) set screws)
Freewheel Adaptor Set Screw
6702201
Set Screw for Freewheel Adapter
Saddle Hardware
6702140
Western Saddle Support Bar Clamps (2 Pcs, DOES NOT INCLUDE NUT)
Rear Hub Bearings
Cartridge Bearings
Basket Hardware
6702181
Trike Basket Mounting Hardware
Touch-up Paint
670226
Touch-up Paint
Battery
670840
Li-Ion Battery, 36V/10.4Ah for E350-Trike
Battery Charger
670843
Smart Charger, 36V/3A for E350-Trike
Other
Weight Limit
250 Lbs.
Recommended Fit
5'0" to 6'4"
Disc Brake Adapter
120465
Disc Brake Adapter (For 15mm axle)
Motor
640658
Bafang 350W/36V Hub Motor
UI/Display
670838
King Meter High Contrast LCD Display, Handlebar Mount
Throttle
670839
King Meter Thumb Throttle, LH
