Frameset
Frame
670114
High Tensile Steel, TIG-Welded
Front Frame
Delta Crank Boom, High Tensile Steel
Fork
High Tensile Steel, TIG-Welded
Drivetrain
Rear Shifter
SunRace 7-Speed Twist Shifter
Rear Derailleur
SunRace, Long Cage
Freewheel
(7-Speed) 13-32T
Freewheel Adapter
Freewheel Adapter Threaded
Crank Set
3-Piece Alloy W/Integrated Chain Ring, 38T, 170mm, Black
Bottom Bracket
Steel, Caged Bearings, 68 x 119mm
Chain
K.M.C. 1/2 x 3/32'' (286 Links)
Chain Tube Bracket
Double Spring w/Hardware
Chain Tube Clamp
Clamp w/Hardware
Brakes
Front Brake
Alloy, Linear Pull, Black
Rear brake
Promax DSK-400 Disc w/160mm Rotor
Components
Steel, 25.4 x 34 x 30mm, Black
Handlebar
Steel, Recumbent w/2 Bottle Braze-ons
Stem
Steel, 25.4 x 220mm Quill x 40mm Ext. x 25.4 Clamp
Grips
EVA Rubber, Locking, 130mm Left / 65mm Right
Front Brake Lever
Linear Pull, w/Lock, Black/Silver
Rear Brake Lever
Linear Pull, w/Lock, Black/Silver
Wheels
Front Hub
37900
Steel, 36H x 14G with 3/8" Bolt-On Axle, Black
Rear Hub
Trike Steel, Pinned, Steel, 36H, Black
Front Rim
20'' x 36H x 14G, Alloy, Black
Rear Rim
20'' x 36H x 14G, Alloy, Black
Spokes
14G UCP with Brass Nipples
Front Tire
Kenda Kwest 20 x 1.50", Black Wall
Rear Tire
Kenda Kwest 20 x 1.50", Black Wall
Replacement Parts
Rear Axle
Rear Axle, Trike, 14.8 x 765mm (INCLUDES 1 AXLE, 2 NUTS, 2 WASHERS, 1 AXLE SPACER)
Axle Bearing
Rear Unit Axle Bearing 15id x35od x11w X3-SX/AX
Axle Retaining Nut
Rear Unit Axle Nut (FOR 14.8mm AXLE)
Seat Frame
50181
R-Type 1-Pc Steel, Black
Seat Mesh
R-Type 1-Pc Seat Back Mesh
Seat Mount
Steel for Eco Delta/Tad 50mm TT
Seat Mount Binder
QR M6x95mm Alloy, XL Lever
Upper Strut
Steel 150mm Black
Upper Strut Washer
Curved Nylon Washer
Lower Strut
Steel, Pin Type, 700mm Universal
Lower Strut Slide Bolt
Lower Strut Bolt and Nut
